Important notice: Bridge sensors are internally connected to input number 1, current sensors are
connected to input number 2 and voltage sensors are connected to input number 3. Enabling a different
type of input can result in incorrect measurements.
7.5.8 Bridge Input
Scroll to “BRIDGE INPUT” from “INTERFACE” using the▲▼ keys and press ENTER.
Use the◄►keys to either enable or disable the Bridge Input.
Depending on the type of sensor defined in the current sensor profile, a warning message will be
displayed when attempting to enable an input type which is not matched with the sensor configuration.
For example, if the active channel is defined as a bridge input the following warning message will appear
on the screen when activating a different input setting:
CURRENT OUTPUT
POWER OUTPUT
► BRIDGE INPUT
VOLTAGE INPUT
SELECT DESIRED
ACTIVITY
USING ◄,► KEYS
[ENABLE]
WARNING!
EXISTING SETTING
MAY BE CHANGED
ACCEPT CANCEL
