7.2.7 Alarm Configuration
Scroll to “ALARM CONFIGURATION” in “SYSTEM SETTING” using the▲▼ keys and press ENTER.
The Alarm threshold levels are set in the sensor profile (Refer to section 6.1.3.9), Refer to the drawings on
page 44 for examples regarding alarm THD levels.
Using the◄►keys set the Alarm Configuration to Latched or Non-Latched.
Definitions:
Latched alarm: Holds the alarm activated until a reset function (manual reset or auto reset) is performed.
Non-Latched alarm: The alarm will turn OFF if the current value goes outside the alarm operating range
(enters none alarm area).
SELECT DESIRED
ALARM CONFIG
USING ◄,► KEYS
[LATCHED]
SAMPLING RATE
PEAK / VALLEY
AUTO RESET
► ALARM CONFIG
WOULD YOU LIKE
TO SAVE AS
DEFAULT?
<YES> <NO>
