7.1.3.1 Sensor Configuration
Scroll to “SENSOR CONFIG” from “NEW CHANNEL” using ▲▼ keys and press ENTER to set a new
channel. “SENSOR CONFIG” can also be selected from “EDIT CHANNEL” to make modifications on
the existing channels except channel 1. Use the ◄►keys to select the sensor type as either “FULL
BRIDGE”,”VOLTAGE OUTPUT”, or “CURRENT OUTPUT”.
Any time a new sensor type is selected, which was not defined before, the device will automatically
calibrate itself after it loads the new profile. The following messages will be seen on the screen.
The following message may be seen if the sensor type is the same as current profile.
OPERATION
WAS EXECUTED
SUCCESSFULLY
(HIT ENTER/BACK)
AUTO CALIBRATION
IN PROGRESS
PLEASE WAIT 12
…
LOADING PROFILE
IN PROGRESS
PLEASE WAIT 30
SELECT DESIRED
SENSOR TYPE
USING ◄,► KEYS
[FULL BRIDGE]
► SENSOR CONFIG
DIRECTION
UNIT SELECTION
SENSOR CAPACITY
To Next Page
