7.1.3.7 Calibration
Scroll to “CALIBRATION” from “NEW CHANNEL” using ▲▼ keys and press ENTER to set it for the
new channel. “CALIBRATION” can also be selected from “EDIT CHANNEL” to make modifications on
the existing channels except channel one.
Note: This function is dedicated for precise calibration (live calibration), however if the user would not
like to apply the load, in the sensitivity selection (6.1.3.5 & 6.1.3.6) manipulating method must be done
accurately otherwise the calculation is not correct.
For example: Using a calibration certification with the sensitivity, the number must be entered in the
sensitivity selection (6.1.3.5& 6.1.3.6) and this step can be skipped. However it is recommended to use this
step and manually live calibrate the sensor.
If user does not have actual sensitivity and has already entered an estimated value in Sensitivity Section
(6.1.3.5 & 6.1.3.6) this step must be executed carefully.
After performing all calibration steps and entering zero load and full scale, device is able to calculate
the actual SENSITIVITY value and update it. SENSOR CONFIGURATION menu will now contain
the actual value.
7.1.3.7.1 Zero Load (+)
Scroll to “ZERO LOAD (+)” from “CALIBRATION” using the ▲▼ keys and press ENTER.
OPERATION
WAS EXECUTED
SUCCESSFULLY
(HIT ENTER/BACK)
APPLY
ZERO LOAD(+)
CALIBRATION
THEN PRESS ENTER
ZERO LOAD (+)
► FULLSCALE (+)
ZERO LOAD (-)
FULLSCALE (-)
SENSITIVITY(-)
► CALIBRATION
PULSE/ROTATE
SERIAL NUMBER
