7.5.3 Relay 1 Output

Scroll to “RELAY1 OUTPUT” from “INTERFACE” using the▲▼ keys and press ENTER.

Use the◄► keys to enable or disable Relay 1 output.

The configuration of the Relay 1 Output should be set under the output configuration menu. Refer to

section (6.4.2) for more details.

Relay 1 is mapped to alarm high and will be affected by the alarm settings under the system setting

menu. Refer to section (6.2.8) for more details on alarm activity.

A prompt will be shown to set this value as a default setting.

Whenever the Relay 1 Output is enabled a check mark showing that this feature is enabled will be seen

on the display.

WOULD YOU LIKE

TO SAVE AS

DEFAULT?

SELECT DESIRED

ACTIVITY

USING ◄,► KEYS

[ENABLE]

USB OUTPUT¾

ASCII OUTPUT

► RELAY1 OUTPUT

RELAY2 OUTPUT
