7.5.2 ASCII output

Scroll to “ASCII OUTPUT” from “INTERFACE” using the▲▼ keys and press ENTER.

Use the◄► keys to either enable or disable the ASCII output.

The termination character configuration should be set in the Digital ASCII menu within the Output

Config menu. Refer to section (6.4.1) for more details.

The ASCII output is disabled when the IPM650 sends and receives packet information from the

computer.

A prompt will be shown to set this value as a default setting.

Whenever the ASCII Output is enabled a check mark showing that this feature is enabled will be seen on

the display.

WOULD YOU LIKE

TO SAVE AS

DEFAULT?

SELECT DESIRED

ACTIVITY

USING ◄,► KEYS

[ENABLE]

USB OUTPUT¾

► ASCII OUTPUT

RELAY1 OUTPUT

RELAY2 OUTPUT
