Whenever the Voltage Input is enabled a check mark showing that this feature is enabled will be seen on
the display.
Important notice: Bridge sensors are internally connected to input number 1, current sensors are
connected to input number 2 and voltage sensors are connected to input number 3. Enabling a different
type of input can result in incorrect measurements.
7.5.10 Current Input
Scroll to “CURRENT INPUT” from “INTERFACE” using the▲▼ keys and press ENTER.
Use the ◄►keys to either disable or enable the Current Input.
BRIDGE INPUT
VOLTAGE INPUT
► CURRENT INPUT
PULSE INPUT
SELECT DESIRED
ACTIVITY
USING ◄,► KEYS
[ENABLE]
WARNING!
EXISTING SETTING
MAY BE CHANGED
ACCEPT CANCEL
