7.3.2 Duration (SEC)
Scroll to “DURATION” from “DATA LOGGING” using the▲▼ keys and press ENTER.
Use the◄► and the▲▼ keys to select the desired duration in seconds; therefore, from 0 to 9999 seconds
can be selected.
Note: The duration that can be set is limited by the following formula:
Max Duration (sec) = Integer (21845/ sampling rate)
SPS
5
10
25
30
50
60
100
200
Max D
4369
2184
873
728
436
364
218
109
SPS
400
600
800
960
1200
1600
2400
4800
Max D
54
36
27
22
18
13
9
4
For example:
If the sampling rate has been set to 10 Samples per Second (SPS) the duration, in second, can be selected
up to 2184.
In the case of HALF SPEED the duration time can be twice as long.
If the device has been set to 10 Samples per Second (SPC) and HALF SPEED logging rate is selected, the
duration, in second, can be selected up to 4368.
SELECT DESIRED
VALUE
USING ARROW KEYS
[0000]
LOGGING RATE
► DURATION(SEC)
ACTION
------------
