7.4.5 Current Value
Scroll to “CURRENT VALUE” from “OUTPUT CONFIGURATION” using the▲▼ keys and press
ENTER to define the current value.
Use the◄► keys and press ENTER to select any of the following Ranges: 0-20 mA, 4-20 mA, 0-25 mA or
5-25 mA.
A prompt will be shown to set this value as a default setting.
SELECT DESIRED
CURRENT VALUE
USING ◄,► KEYS
[0-20 mA]
ALARM RELAY2
VOLTAGE CONFIG
► CURRENT VALUE
CURRENT CONFIG
WOULD YOU LIKE
TO SAVE AS
DEFAULT?
<YES> <NO>
