20
Video Appearance
Brightness, contrast, saturation, sharpness and orientation are adjusted.
Brightness: The range is from 0 to 255, the default is 128.
Contrast: The range is from 0 to 255, the default is 128.
Saturation: The range is from 0 to 255, the default is 128.
Sharpness: The range is from 0 to 255, the default is 128.
Orientation: Select vertical flip or horizontal mirror an object.
Exposure control
Selecting the right exposure control mode depends on the installation site’s environment. 3
modes are available; normal, flickerless-50Hz and flickerless-60Hz. (During the normal mode, it
automatically adjusts the shutter speed. If the camera is utilized under the florescent light, it is
recommended to select between flickerless (50/60Hz) modes to compensate the light
flickering.)
Correct exposure value should be selected from the list box to adjust the target brightness for
the automatic exposure setting. The high value makes the image brighter, and the low value
makes the image darker. Select the value as follows: +1.0, +0.6, +0.3, 0, –0.3, –0.6, –1.0(EV)
BLC
Identify the area where the image is underexposed due to strong light from nearby area for
camera to increase exposure amount.
DSS
Turn on or off the digital slow shutter, depends on needs.
Day & Night
Three different day/night modes are supported: Auto, Day, and Night. Select the desired mode
based on the installation environment. Default value is Auto.
Image Signal Processing
When noise filter value is 0, the noise filter is off. The noise suppression is performed to the
maximum when the value set is 15. The video quality will suffer when the value is set to the
highest. The range is from 0 to 15, and the default is 0.
Using the Preview button
Preview window appears with current setup visuals. When settings are applied, the preview
window displays the user’s latest modification. The preview window displays respected video
channel (tab) that the user is currently modifying.
