Ganz IP Camera - Page 48

48
Restriction of Stream Bandwidth
You can limit the stream bandwidth. To set the stream bandwidth limitation, input the desired
number on the text box (from 0 to 30Mbps). For example, if you input 30Mbps, then all users
accessed to the system share the specified bandwidth.
RTSP Configuration for UNICAST
Session name
Type the appropriate session name. The allowed range for the session name is 64 characters
with alphabets, Arabic numbers, and underscore bar(_).
Include audio stream
Check this box to include the audio stream in addition to the video stream.
Include Metadata
Check this box to add the metadata.
Enable QoS DSCP
By enabling the Quality of Service (QoS) feature, you can specify priority level of network
traffic for video, audio, and metadata (motion detection and VCA). For each traffic type,
determine the DSCP (Differentiated Services Codepoint) value, which represents a QoS class in
the Differentiated Services (DiffServe) model. For the details about the DiffServ standard, refer
to RFC2474 and RFC2475.
RTSP configuration for MULTICAST
IP Address
In order receive the streaming data from the device, set the IP address of group which is used
for PC to join. ‘0,0,0,0’ is configured as a factory default and it enables router program to
generate the available IP for the device automatically. If you want to use specific address, type
the address in the blank.
Note
i
RTP multicast is not allowed for streaming even if the address and the port
information are known.
How does auto configuration of IP address works?
As the session name for each RTP session is defined already on the server, your PC can get the
stream by the ‘rtsp:// rtsp server ipaddress : port / rtp session name’ without the manual
decision of IP address on the webpage.
