Page 4-72 LMM for the Kodiak 100
190-02102-00 Rev.4
RAM Status Indicator • Internal SW execution
failure or RAM
component failure.
• Ensure the software,
including FPGA, is up to
date.
• Replace the GWX 80.
• Possibly viewable in config
mode.
FPGA Status Indicator • Internal FPGA
component failed.
• Replace the GWX.
• Viewable in config mode.
Attitude Status Indicator • Valid attitude
information is not
being received on
neither HSDB, ARINC,
nor analog.
• Verify the unit is properly
connected to the systems
AHRS databus (HSDB or
ARINC) or Analog Gyro (if
applicable).
• Viewable in config mode.
Antenna Status Indicator • Antenna Clearance
test failure.
• Ensure nothing is blocking
the unit but running the
antenna clearance test by
putting the radar into
standby mode. This should
be done with and without
the radome.
• Replace the GWX.
• Viewable in config mode.
Table 4-10. GWX Processor Troubleshooting (Continued)
Fault Indication Cause Solution
Uncontrolled if Printed

Garmin G1000 Specifications

General

Display Type	LCD
Primary Flight Display (PFD)	Yes
Multi-Function Display (MFD)	Yes
Terrain Awareness	Yes
Autopilot Integration	Yes
Integrated Flight Deck System	Yes
Weather Radar	Optional
Traffic Advisory System (TAS)	Optional
Terrain Awareness and Warning System (TAWS)	Yes
Resolution	1024 x 768 pixels
Weather Data	Yes
Navigation	Yes
AHRS	Yes
Air Data Computer (ADC)	Yes
Interfaces	ARINC 429, RS-232
Certification	TSO certified
Traffic Information	Optional (requires ADS-B or TCAS)
