Page 2-18 LMM for the Kodiak 100
190-02102-00 Rev.4
Table 2-4. GMA 1360D Control Functions
1 COM1 MIC Selects the #1 COM for transmitting. The COM1 receiver is
simultaneously selected when this key is pressed, allowing
received audio from the COM1 receiver to be heard. COM2
receiver audio can be added by pressing the COM2 Key.
When the PTT is active the annunciation will be flashing.
2 COM1 When selected, the #1 COM receiver audio can be heard.
3 COM2 MIC Selects the #2 COM for transmitting. The COM2 receiver is
simultaneously selected when this key is pressed, allowing
received audio from the COM2 receiver to be heard. COM2
can be deselected by pressing the COM2 Key, or COM1 can
be added by pressing the COM1 Key. When the PTT is active
the annunciation will be flashing.
4 COM2 When selected, the #2 COM receiver audio can be heard.
5 AUXMIC Reserved for optional audio.
6 AUX Reserved for optional audio.
7 DME Turns optional DME audio On or Off.
8 NAV1 When selected, the #1 NAV receiver audio can be heard.
9 ADF Turns optional the ADF receiver audio On or Off.
10 NAV2 When selected, the #2 NAV receiver audio can be heard.
11 PA Selects the passenger address system. The selected COM
transmitter is deselected when the PA Key is pressed. A solid
annunciation indicates PA mode is active, while a flashing
annunciation indicates PTT has been keyed.
12 TEL Selects/deselects the TEL audio source and assigns the
Bluetooth device to the TEL audio. Press the TEL button until
the annunciator turns blue. The annunciator will cycle from
OFF to WHITE to BLUE. WHITE selects the wired audio
source and BLUE selects the Bluetooth audio source. The
Bluetooth audio source can only be assigned to one source at
a time. Once the Bluetooth audio is assigned to an audio
source, the remaining entertainment audio sources will only
cycle between OFF and WHITE.
13 CREW ICS Controls the crew intercom system. Press and hold to enable/
disable the onside Bluetooth recording mode.
