1.4.3 The Whole View (Figure 1-3)
**Stand for Puma III 60 is an optional item.
**Stand for Puma III 132S is a standard item.
Figure 1-3
Roll Holder – holds
and supplies the roll
media for cutting.
Roll Holder Guide
Bushes – serve to
keep the roll media in
place when media is
pulled from the roll.
T-Stand –supports
the cutting plotter
Stand Beam –
stabilizes the body.
Roll Holder
Support – supports
roll holders.
T-Stand –supports
the cutting plotter
