General Information 1-1
Chapter 1 General Information
1.1 Introduction
Puma III series cutting plotters have been designed to produce computer-generated images
or perform contour cutting on sheets or rolls of vinyl media.
This manual covers the following models of Puma III series cutting plotters:
‧P3-60 for media width: 70mm (2.76”) ~ 719mm (28.3”)
‧P3-132S for media width: 70mm (2.76”) ~ 1470mm (57.87”)
1.2 Package Items
The package of the Puma III model contents the items listed below, please check carefully.
If you find any item missing, please consult your local dealer for further assistance.
S
S
t
t
a
a
n
n
d
d
a
a
r
r
d
d
I
I
t
t
e
e
m
m
Q
Q
u
u
a
a
n
n
t
t
i
i
t
t
y
y
1. Cutting Plotter 1
2. Stand Set ( for P3-132S only, optional for P3-60)
 2 piece of T-shape stand
 1 piece of stand beam
 20 pieces of M6 screws
 1 piece of M5 L-shape hexagon screw driver
 1 piece of Installation Guide for Stand Set
1
3. Flexible Media Support System Package
Items
P3-60
P3-132S
1 set of Roll Media Flange (2 pieces)
V
1 set of Roll Holder (2 pieces)
V
1 set of Roll Holder Guide Bushes (4 pieces)
V
1 set of Roll Holder Support (2 pieces)
V
32 pieces of M6 screws
V
1 piece of M6 L-shape hexagon screw driver
V
1 piece of Roll Base
V
1
