GCC Technologies P3-60 - Puma III Specification

Puma III User Manual
Puma III Specification A-1
Puma III Specification
Model Name/No.
P3-60
P3-132S
Operational Method
Roller-Type
Max. Cutting Width
600 mm (23.6 in)
1300 mm (51.18 in)
Max. Cutting Length
50 m(164 ft)
Max. Media Loading Width
719 mm (28.3 in)
1470 mm (57.87 in)
Min. Media Loading Width
50 mm (1.97 in)
Acceptable Material Thickness
0.8 mm (0.03 in)
Number of Pinch Rollers
2
4
Motor Drive
DC Servo Control
Cutting Force
400 g
Max. Cutting Speed
849 mm /sec (33.4 ips) (at 45° direction)
Offset
0~1.0 mm (with an increase of 0.025 mm)
Mechanical Resolution
0.009 mm (0.00035")
Software Resolution
0.025 mm (0.00098")
Distance Accuracy
±0.254 mm or ±0.1% of move, whichever is greater
Repeatability
±0.1mm up to 3 meters (* certified media)
Automatic-Aligning System
Completely Automatic Contour Cutting System for print to cut solution
Memory Buffer
4MB
Interfaces
USB 2.0 (Full Speed) and Serial (RS-232C)
Type of Command
HP-GL, HP-GL/2
Control Panel
LCD (20 digits x 2 lines), 14 Keys, 1 Power LED
Diameter of Blade 2 mm
Dimension (HxWxD) mm
220x 879x258
8.67 x34.61x10.16 in
1065 x 1632 x 620 (including stand)
41.93 x62.25x24.41 in
Net Weight
13kg / 28.6lb
53 kg / 116.4 lb
Stand
Optional
Standard
Power Supply
AC 100-240V, 50~60 Hz (auto switching)
Power Consumption
Max.110watts
Environment Temperature
15°C ~35°C
/ 60°F ~86°F (operating)
Environment Humidity 25%~ 75% relative humidity (operating)
 Compatible with Windows 7 and above & MAC OS X 10.6 and above. (*Purchasing serial number for “Sure
Cuts A Lot” software to work with Mac OS.)
 The specification and data sheet may vary with different materials used. In order to obtain the best output
quality, please maintain the machine regularly and properly.
 GCC reserves the right to change the specifications at any time without notice.
 GCC certified material in tracking is Avery MPI 3000.
