7-4 170 Series Monitor Revision C
2000947-004
Serviceable Assemblies: Transducer Plug Replacement Kits
Handling Precautions
Transducers are delicate measuring instruments and must be handled accordingly.
Transducer damage can be avoided by taking the following precautions:
Avoid banging or dropping transducers.
Refrain from wrapping transducer cables around transducer body.
Do not immerse transducers in aqueous cleaning solutions.
Do not pull on cables when removing transducer plugs from the monitor front-
panel connectors; remove plugs by grasping the gripper.
Equipment Required
You will need the following equipment:
Green
1
Stranded Wire (approximately 6 inches)
#24 AWG for tocotransducers and ultrasound transducers
#26 AWG for FECG cable/legplates
#26 AWG Blue Stranded Wire (approximately 4 inches) for FECG Cable
Wire Cutter/Stripper
Soldering Iron and Solder
Shrink Tubing
Oetiker Pincers (for Nautilus Tocotransducers only)
2
1
The color green is specified for consistency with factory builds and the wiring charts contained in this
document.
2
This tool is required to place an Oetiker clamp on a 2264 Series Nautilus Tocotransducer. You can
order the Standard Pincers (No. 1098) or Side Jaw Pincers (No. 1099) from Oetiker, Inc., P.O. Box 93,
Livingston, NJ 07039. The telephone number is: 201-992-1920.
