Revision C 170 Series Monitor 7-17
2000947-004
Serviceable Assemblies: Nautilus Transducer Cable Replacement
Procedure
1. Unplug the transducer from the monitor or telemetry transmitter.
2. Use the screw cap extraction tool to pry off the five screw caps (Figure 7-5).
Discard all caps.
CAUTION
HANDLING–Take care not to damage the base sealing groove.
3. Remove the five sealing screws and discard.
4. Remove the transducer cover and flat-seal o-ring. Discard both items.
5. Remove the cable connector according to the transducer type (Figure 7-6):
Tocotransducer
a. If the PC board header is on the underside of the board (2264 GAX/HAX/
JAX/KAX/LAX/MAX only), remove the three self-tapping screws from
the board to gain access. Set aside screws.
b. Observe the orientation of the cable connector in the PC board header, then
unplug.
Ultrasound Transducer
a. Unscrew the green cable ground wire from the PC board. Set aside screw.
b. Unsolder the green and clear cable wires from the PC board.
6. Loosen the cable nut set screw, then unscrew the cable from the cable nut. Set
aside screw and cable nut.
7. Remove the cable from the transducer base.
CAUTION
CABLE HANDLING–Do not place undue stress on cable wires
and shielding. Do not damage the cable o-ring or the hole in the
transducer base.
8. Feed the connector end of the new cable through the hole in the transducer base.
The cable o-ring should be seated in hole.
