Revision C 170 Series Monitor 7-21
2000947-004
Serviceable Assemblies: Tocotransducer Calibration
Nautilus Tocotransducers
Calibrating a Nautilus Tocotransducer requires a Calibration Kit. Refer to Table 7-9
to order the correct kit. Unpack the kit and ensure it contains the items listed in
Table 7-10. If something is missing, contact your GE Service Representative
immediately. The text of the instruction sheet is repeated here for informational
purposes.
Table 7-9. Kit Summary
Nautilus Transducer
Type and Cat. No. (REF)
Cable Kit
Cat. No. (REF)
Loop-Style Tocotransducer, 2264 DAX/EAX/FAX/KAX/LAX/MAX 2003663-001
Button-Style Tocotransducer, 2264 AAX/BAX/CAX/GAX/HAX/JAX 2003664-001
Table 7-10. Packing List
Item Qty
Transducer Case Top 1
Flat-Seal O-Ring 1
Sealing Screw, #4-40 x 5/16 in 6
Screw Cap, Curved 4
Screw Cap, Flat 1
Belt Knob
a
a
The belt knob is included in button-style kit 2003664-
001 only.
1
Instruction Sheet 1
