108 GENERAL D400 SUBSTATION GATEWAY USER’S MANUAL
CHANGING THE COMPACTFLASH CHAPTER 8: SERVICING THE D400
Figure 61: Replace the main CompactFlash card
To change the User
CompactFlash card
1. Power down the D400.
2. Using a Phillips Screwdriver, remove the screws from the CompactFlash slot cover
located on the front panel of the D400 main module.
3. Press the Eject button to eject the CompactFlash card.
4. Insert the new CompactFlash card into the slot.
5. Replace the CompactFlash slot cover and secure it with the screws.
6. Power up the D400.
Figure 62: Change the user CompactFlash card
Eject button
Connector P2
PC/104-Plus 10/100BaseT
Ethernet Module
