76 GENERAL D400 SUBSTATION GATEWAY USER’S MANUAL
POWER CONNECTIONS CHAPTER 5: POWERING UP THE D400
Redundant power supply
The D400 may be provided with an optional redundant power supply unit in Power Supply
Slot 2. The second power supply provides continuous power to the D400 in the event the
primary power supply unit fails.
Additional protection can be provided if a secondary external power source is available. In
the event the primary power source fails, an automatic switchover will take place to the
redundant power source to ensure continuous power to the D400.
Power configurations
The D400 supports the following power configurations:
• Single External AC Power Source
• Single External DC Power Source
• Two External AC Power Sources with optional redundant D400 AC-DC Power Supplies
• Two External DC Power Sources with optional redundant D400 DC-DC Power
Converters
Power input ranges
Table 20: AC-DC Power Supply
Table 21: DC-DC Power Supply
Applying AC voltages to a DC-DC power supply may cause irreparable damage.
Power connections
The D400 accepts power connections through two terminal blocks on the rear panel:
•Terminal block TB1 is reserved for connecting power from one or two external sources
to the D400.
•Terminal block TB2 provides contact closure outputs for power supply fail and system
fail alarms.
Rated voltage range 100 to 240 VAC / 100 to 300 VDC with overvoltage protection of
110% to 150%
Rated power If the unit is… Then the rated power is…
AC 127 VA maximum
DC 135 W maximum
Inrush current at
25°C on cold start
26.5 A
peak
(< 145 VAC/205 VDC)
40 A
peak
(< 264 VAC/370 VDC)
Rated frequency 47 to 63 Hz (50/60 Hz)
Rated voltage range 20 to 55 VDC with overvoltage protection of 110% to 150%
Rated power 135 W maximum
Inrush current at 25 °C 35 A
peak
(< 60 VDC)
