D400 SUBSTATION GATEWAY USER’S MANUAL GENERAL 123
Modification Record
Version Revision Date Author Change Description
1.00 0 July 12, 2006 S. Tessari Document created
1 Nov. 17, 2006 E. Stuhr
S. Tessari
Revisions as required by TUV.
Deleted Supported Devices sections.
Moved signal definitions to Chapter 4 and added more connections information.
Edited whole document for consistency and correctness to current product specs.
Added Chapter "Setting Up the D400."
2 Dec. 20, 2006 S. Tessari Converted to single-source
Feb. 28, 2007 S. Tessari Added RoHS and recycling info, updated RS-485 channel numbering order
3 July 31, 2007 S. Tessari Added chapter 7, updated network interface setup, updated ordering guide. General
editing for commercial release.
4 Sept. 12, 2007 S. Tessari Updates to hardware platform
5 Sept. 29, 2007 M. Haska Revisions to power/system alarms sections and Local HMI functionality
6 Nov. 29, 2007 M. Haska Updated required JVM version from 5.0 to 6.0
7 June 16, 2008 M. Haska Added 1.0 GHz CPU information
8 Sept. 10, 2008 M. Haska Added info on 100Base-FX Hot Standby Fiber Optic Ethernet Adapter
1.10 0 Nov. 6, 2008 M. Haska Added system redundancy and system status manager
1 Nov. 10, 2008 M. Haska Minor revision to system redundancy wiring diagrams and procedure
2 Dec. 3, 2008 M. Haska Added minor notes to redundancy section
3 Jul. 21, 2009 M. Haska Added modem settings and redundant power feed in redundant serial panel
diagram
1.20 0 Apr. 6, 2010 M. Haska Changed RS-485 adapter card default setting to 2-wire.
1.30 0 Jan 27, 2012 R. Rees Edited entire document for GE Digital Energy manual layout and format.
Added content for Hot Standby configuration.
1 Feb 17, 2012 R. Rees Added GE part numbers for CompactFlash to the
Changing the CompactFlash
section.
2 Mar 20, 2012 R. Rees Added Appendix B: List of Acronyms
3 Jun 29, 2012 R. Rees Updated the RoHS Material Declaration.
4 Aug 31, 2012 R. Rees Added Dual ethernet upgrade kit for card 580-3410
5 May 7, 2013 R. Rees Added product disclaimer.
6 Aug 15, 2013 R. Rees Removed product disclaimer.
Updated the RoHS Material Declaration Data Content by Assembly table.
Updated IRIG-B input adapter section; removed SW3.
Corrected the Power Fail Alarm section.
Updated the Changing the Compact Flash section.
7 Oct 18, 2013 R. Rees Added note for 580-3410 dual ethernet card; not used with 1 GHz CPU.
Replaced 501-0612 part number with D400-DE-UPGRADE.
Added Battery Removal section.
8 Nov 6, 2013 R. Rees Added Service Pack and Service Updates information for firmware to Chapter 2.
9 Nov 29 2013 R. Rees Added Product Specifications > Environmental > Operating Temperature notes.
