Maintenance
2000966-386D Dash™ 3000/4000/5000 A-13
1. Insert the battery into the battery charger and wait for the RUN LED light to
illuminate (approximately three minutes).
2. If the RUN LED light does NOT illuminate, complete the following steps:
a. Remove the battery from the battery charger.
b. Insert the battery into the battery charger and let the battery trickle charge for
two to three minutes while the FAIL LED flashes. If the RUN LED light
illuminates, ignore it.
c. Watch the battery charger LEDs and immediately remove the battery from
the battery charger when the FAIL LED stops flashing AND remains
illuminated, OR when both the RUN and CONDITION LEDs flash.
d. Wait for one to two seconds, then reinsert the battery into the battery charger.
The RUN and CONDITION LEDs will flash for five to ten seconds while
the charger initializes the battery. If the FAIL LED illuminates, remove the
battery and reinsert it into the battery charger.
e. Watch the battery charger LEDs. The RUN LED should stop flashing and
remain illuminated for approximately one minute, then the CONDITION
LED should stop flashing. At this time, the battery is awake and being
charged.
Recycling
WARNING
EXPLOSION HAZARD—DO NOT incinerate the battery or store
at high temperatures. Serious injury or death could result.
When the battery no longer holds a charge, it should be replaced. The battery is
recycleable. Remove the old battery from the monitor and follow your local recycling
guidelines.
In the United States and Canada, the Rechargeable Battery Recycling Corporation
(RBRC) can help you locate your nearest rechargeable battery collection site. You can
contact RBRC by telephone (1-800-8-BATTERY) or by accessing their internet web
site (www.rbrc.org
).
Troubleshooting
There are three conditions that activate battery alarms:
Low battery
Battery failure
Charger failure
Refer to the following table for solutions to alarm messages that display in the ECG
waveform area.
