Printing
2000966-386D Dashâ„¢ 3000/4000/5000 7-3
Printed Output
All waveforms begin with 10 seconds of delayed data. The header information
printed with the waveforms is real time data. Print output contains the following basic
information in the header.
îš„ Type (alarm, manual or saved)
îš„ Alarm violation (if any)
îš„ Unit name, bed number and patient name
îš„ Date and time
îš„ Patient-monitor type
îš„ Alarm volume
îš„ Speed
îš„ Lead failed (if any)
îš„ Heart rate
îš„ Arrhythmia call (if any)
îš„ Pace mode (if on)
îš„ Arrhythmia mode (full, lethal, off)
îš„ PVC count (if arrhythmia mode is on)
îš„ ST value for top displayed lead (if on)
îš„ ECG filter (Hz range)
îš„ Monitored parameter values
ALARM GRAPH
PRINT ON ALARM
Select whether alarms print automatically.
SPEED Select the print speed. The slower the speed, the more
condensed the data.
NOTE
Alarms print at 25 mm/sec. Laser printers do not
support 0.1 mm/sec print speed.
TIMED GRAPH
TIMED PRINT
Select the amount of time to print for each manual print job.
NOTE
Arrhythmia alarms run until a normal sinus rhythm is
detected or the print job is manually stopped. All other
alarms run for 20 seconds or until the print job is
manually stopped.
GRAPH BP INVASIVE
PRINT BP INVASIVE
Select the blood pressure waveforms. When selected, BP
waveforms are the only parameters that can be printed.
They print on one scale on the full grid space.
NOTE
You cannot switch BP selections while a print job is in
progress. To select a different BP, you must stop the
current job. If a different parameter is printing, the BP
print job is ignored.
Option Function
