Equipment Overview
2000966-386D Dash™ 3000/4000/5000 2-7
Selecting High/Low Values
1. Rotate the Trim Knob control to scroll the pointer up and down the list.
2. When the pointer is in front of the desired option, press the Trim Knob control to
highlight the parameter.
3. Turn the Trim Knob control to highlight the low or high limit.
4. Press the Trim Knob control and rotate to change the value.
5. Press the Trim Knob control to select the value.
Indicators
Alarm Light
Indicates an alarm condition. An optional alarm light indicator is built into the handle
or the display bezel.
Flashing red — CRISIS patient status alarms.
Flashing yellow — WARNING patient status and system status alarms.
Power
On the Dash 3000 monitor front panel, there is an LED labeled AC and an LED
labeled Battery. When the AC LED is illuminated, the monitor is running on AC
power. When the Battery LED is illuminated, the monitor is running on battery
power.
On the Dash 4000 and Dash 5000 monitors, the following indicates the monitor’s
power source.
820A
Power Indicator
AC illuminated — The monitor is running on AC power.
Battery illuminated — The monitor is running on battery power.
Charging Status
Indicates the battery charging status of the internal batteries. One indicator for each
battery (A and B).
821A
Charging Status Indicator
Yellow — The battery is charging.
