FULL SET-UP Continued
Key/selection Function and comments
ALT
data entry
SPEED
SETUP contd...
SETUP + KEY PRESS
Altitude correction value
Full or minimum set-up selected in conƉguration.
[AUTO ZERO]
[ON]
Auto zero function
Temperature for true airspeed
MACH
Enter Pitot temperature
Mach limit
[OFF]
[CAS/TAS]
[CAS]
[TAS]
[Pt TEMPERATURE]
data entry
DeƉrihfy current limits
Removes Mach limit
OrefpiwWeglpmqmt
[DEFAULT]
[OFF]
[ON]
Enter new Mach limit data entry
RATE TIME
[WAIT/TIME ON F1]
Set-up WAIT and TIME time periods
For F1
[TIME] Change to TIME
[WAIT] Change to WAIT
of TIME time
of WAIT time
See [Wait/Time on F1]
data entry
data entry
[WAIT TIME F2]
See [Wait/Time on F1] [WAIT TIME F3]
RATE
Automatic
Automatic airspeed rate
[ON]
[OFF] Manual
LEAK MEASURE
[AUTO LEAK]
[ON]
A
uto leak recovery on or oƇ
[OFF]
[AUTO LIMIT]
[ON]
Auto limit recovery on or oƇ
[OFF]
GROUND
See Line Switching Unit User Manual
data entry
PORT
REMOTE Remote mode lock, see conƉguration
