IRECTION 5305880-100, REVISION 3 LOGIQ™ 100 PRO SERVICE MANUAL
Page 9-10 Section 9-1 - Overview
9-1-8 Material List - FEB
OPERATOR CONSOLE ASSY
5304117,5304414,5304240,5304248,5304441,5304596,5306834.
Figure 9-7 FEB Assembly
703
Table 9-7
Item Part Name Part No. Description Qty
703 FEB Assy 5199849 LOGIQ™ 100 PRO 1
704 FEB+DAVINCI Assy 5308177 LOGIQ™ 100 PRO 1
Davinci board
FEB
704
State: RELEASE - Document is released and under formal Change Control. Changes are subject to the ECR/ECO Process.
See the GEHC Myworkshop System to determine the status of this document.
Approved Document - 5305880-100TPH_r3.pdf Page 165 of 197
