GE LOGIQ E9 Service Manual

GE
D
IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL
3 - 72 Section 3-9 - Connectivity Setup and Tips
Scan Screen
6.
The displays the scan screen, prompts you to confirm the patient data set selected, and
displays the non-US volume on the right side of the screen.
7.
To scroll through the dataset, press the Scroll Z Trackball button. Use the Trackball to scroll
through the dataset to find the area of interest.
8.
When done, press Scroll Z again. You are now scanning live on the left side of the screen with
your reference view on the right screen.
Table 3-27 Q/R Support for Volume Navigation

GE LOGIQ E9 Specifications

General

Type	Ultrasound System
3D/4D Imaging	Yes
Transducer Ports	4 active ports
Connectivity	DICOM, USB, Ethernet
Applications	Abdominal, Vascular, Musculoskeletal, Small Parts, Urology, Pediatric, Cardiac, Obstetrics/Gynecology
Transducers	Linear, Convex, Phased Array, Volume
Doppler Modes	Color Doppler, Power Doppler, Pulsed Wave Doppler, Continuous Wave Doppler
Elastography	Yes
Advanced Features	B-Flow, Volume Navigation
Portability	Cart-based system
Display	19-inch high-resolution LCD monitor
