GE
D
IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL
8 - 18 Section 8-4 - Loading / Reloading / Upgrading the Software
9. Wait until all drivers are installed
automatically and the reboot is complete.
DO NOT PRESS ANY KEY, ignore all
messages until the automatic reboot is
complete.
Restart Windows Message
10. Plug in your Service Dongle to ensure that it is recognized and lights up.
From Windows, double-click on My Computer to confirm the CD/DVD drive is mapped to G:\. If
the drive is not mapped to the G:\:
From the Desktop:
a. select “My Computer.”
b. Open C:\remap\newmap.
c. Double-click on newmap.bat to remap the drive.
Remove the Service Dongle.
Table 8-4 Software Load - R4 or later
Steps Corresponding Graphic
