GE
D
IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL
8 - 34 Section 8-5 - Replacing Covers and Bumpers
3.
If the LOGIQ E9 has the Removable Fan
Tray, reinstall the four Phillips screws at the
bottom of the Cover.
Slide the Fan Tray into the LOGIQ E9.
Make sure the Fan Tray SEATS
COMPLETELY into the Card Cage.
Table 8-5 Side Covers removal
Steps
Corresponding Graphic
