GE
D
IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL
Chapter 8 Replacement procedures 8 - 107
8-6-3-2 LCD Monitor V2 Arm assembly replacement (used in R4.x production) (cont’d)
Table 8-68 LCD Monitor V2 Arm assembly installation - R4
Steps Corresponding Graphic
1.
WHEN INSTALLING THE LCD ARM
ASSEMBLY, KEEP THE LCD ARM IN
THE LOCKED POSITION. THE SPRINGS
TO SUPPORT THE LCD CAN CAUSE
THE ARM TO SPRING OPEN CAUSING
SEVERE PERSONAL INJURY AND
PROPERTY DAMAGE.
IF INSTALLING A NEW FRU, KEEP THE
SHIPPING WRAP INTACT TO ENSURE
THE LCD ARM ASSEMBLY IS IN THE
LOCKED POSITION UNTIL THE LCD IS
INSTALLED.
To Next Page
