GE
D
IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL
Chapter 8 Replacement procedures 8 - 151
5. Remove the TGC dust gasket. The
gasket is included with the complete
Lower Panel and the Lower Panel
Circuit Board.
TGC Dust Gasket
Table 8-98 Lower Op Panel Board replacement
Steps Corresponding Graphic
