IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL
8 - 152 Section 8-6 - Replacing Top Console Parts
8-6-10-2-1 Lower Bezel Replacement
Table 8-99 Lower Bezel Replacement
Steps Corresponding Graphic
1. Remove and transfer keycap and
carriers over to the new Lower
Bezel.
Remove and transfer Encoders to
the new Lower Bezel.
Remove and transfer the Trackball
ring of keys parts to the new Lower
Bezel.
Ring of Keys Parts
(used on P/N 5207000-33 and prior only)
