GE
D
IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL
Chapter 8 Replacement procedures 8 - 155
8-6-10-2-3 Depth-Type Joystick Encoder Replacement
Table 8-101 Depth-Type Joystick Encoder Replacement
Steps Corresponding Graphic
1. Remove the elastomer covering
from the Lower Bezel.
Elastomer Cover
2. Flip the board over.
Detach the cable.
Flip the board over again.
Bottom of Board
