GE
D
IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL
Chapter 8 Replacement procedures 8 - 157
8-6-10-2-5 Elastomer Lower Op Panel Replacement
Table 8-103 Elastomer Lower Op Panel Replacement
Steps Corresponding Graphic
1. Align the elastomer guides.
Elastomer
Elastomer Guides - bottom view
