Chapter 8 Replacement procedures 8 - 159
4. Replace the TGC dust gasket. The
clear, plastic backing must be
facing down when the bezel is
installed. (The clear, plastic backing
should be facing up from this view.)
TGC Dust Gasket to Lower Bezel
Table 8-103 Elastomer Lower Op Panel Replacement
Steps Corresponding Graphic
