GE
D
IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL
Chapter 8 Replacement procedures 8 - 169
8-6-12-6 Calibration and adjustments
Temperature is preset to its highest level: 38 degrees C (+/-2 degrees C). It is recommended to retain
default setting.
User can turn dial to adjust the temperature to its lowest level: 32 degrees C (+/-2 degrees C).
8-6-12-7 Verification
Perform the following steps to verify that the product is functioning as intended after this replacement:
1.) Verify that all screws removed earlier have been installed.
2.) If finished, connect cables and Probes removed earlier.
3.) Power up the system to verify that it operates as intended.
4.) Place a closed bottle of gel, applicator end first, in the gel warmer. Verify warmer is operational.
8-6-12-8 Functional Checks
Perform the following functional checks to confirm the system is operational before returning the system
to the customer.
If all are successful, include the following debrief script: LOGIQ E9 Service Manual, Direction
5535208-100, Rev. 2. Equipment passed all required checks and is ready for use.
Table 8-107 Gel Warmer replacement Functional Checks
See:
Section Functional Check Debrief Script
4-2-2 Power ON/Boot Up
LOGIQ E9 Service Manual, Direction
5535208-100, Rev. 2. Equipment passed all
required checks and is ready for use.
4-2-3 Power shut down
4-3-14 Probe/Connectors Checks
4-3-5 B-Mode Checks
4-3-7 System CFM and PWD Checks
4-3-10 Basic Measurements
4-3-18 Mechanical Function Checks
4-3-18-2 Brakes and Direction Lock Checks
