IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL

8 - 212 Section 8-9 - BEP (Back End Processor) parts replacement

Remove the following parts from the BEP, to reinstall in the replacement BEP:

• Option Dongle

• Printer and/or the Printer Tray or the Shear Wave Capacitor Pack if Shear Wave option is

installed.

• BackPlane to BEP cable

• Wireless Card and Antennas, if present

• Patient I/O, if present

• S Video Card, if present

• Shear Wave Capacitor Pack, if present

Table 8-126 BEP removal - R4.x and later

Steps Corresponding Graphic
