IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL
8 - 266 Section 8-10 - Main Power Supply parts replacement
5. Connect the USB Cable from the
4D MC to J28 on the BEP.
Table 8-168 4D MC Reinstallation for Lambda PS
Steps Corresponding Graphic
