GE
D
IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL
Chapter 9 Renewal Parts 9 - 25
47.
Operator Panel Assembly, Lower
Without Trackball
5207000-72
See: Table 9-13
"Operator Panel
Compatible
Configurations" on
page 9-36.
Same as -62 Plus B-Flow Key Top
1Y
48. R5 LE9 Lower Op Panel - Removable
Trackball compatible
5207000-82 1Y
49. Lower Op Panel Assembly 5208000-1 1Y
50.
Operator Panel Frame Assembly,
Lower
5195937 1Y
51.
Inductive Trackball
GA200444
OBSOLETE
Replaced by 5207000-5 1 Y
52.
Improved Inductive Trackball 5207000-5
To become obsolete. If unavailable, order 5341631
1Y
53.
Optical Trackball 5341631
Replaced 5207000-5
1Y
54. Trackball - Removable 5393439-10
Table 9-11 Top Console parts 9 of 18 (Continued)
ITEM PART NAME PART NUMBER DESCRIPTION QTY FRU
P2
P
3
P4
A
uto
Depth
Steer Width
R
L
B
3D/4D
Measure
Comment
Clear
Zoom
C
HI
CF
P
D
I
CW
M
X
Y
Z
PW
Co
n
t
r
ast
V
N
av
Εlasto
Freeze
LOGIQ
L O G I Q
1
2
34
34
LOGIQV
i
ew
