IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL
Chapter 9 Renewal Parts 9 - 41
NOTE: LOGIQ E9 console models 5205000-4 and earlier:
It is recommended to have the system running R2.0.4 or later Application Software and the XY USB
Cable installed to allow the system to release the XY Brakes at shutdown if the console is not locked.
If replacing the new FRUs on a system that is not running R2.0.4 or later, order the Late Request Plan
for FMI 70206 - R2.0.4 Software Upgrade and XYZ USB Cable Update in SN70443A - Closed FMIs on
LOGIQ™ E9, LOGIQ™ 9 and LOGIQ™ 700 Consoles.
Table 9-16 XY Mech Brakes and Brake Motor FRUs Compatibility Chart
New P/N Description Replaces Compatibility Solution / Comments
GA200946
XY
Mechanism
GA200036
Backward
compatible
If replacing this part, it is recommended for
better performance to check the installed XYZ
Motor Controller and update it to 5429346 if
5429346 is not installed yet.
5954000
XY
Mechanism
(USA Mfg.)
GA200946
Backward
compatible
Substitute for GA200946. If replacing this
part, it is recommended for better
performance to check the installed XYZ Motor
Controller and update it to 5429346 if
5429346 is not installed yet.
5429346
LOGIQ E9 XYZ
Motor Controller
with O-ring
Detection
GA200644
GA200795
No.
Only compatible
with P/N GA200946 -
XY Arm Assembly,
and P/N GA200952 -
XY brake Motor
Assembly
N/A
5440179
LOGIQ E9 XYZ
Motor Controller
with O-ring
Detection
5429346
Supports new LCD
Monitor introduced
with R4.x and later
consoles
Use this FRU if the LCD Arm and Monitor are
the new version for R4.x and later, due to the
changes in weight of the new LCD Arm and
Monitor.
5440179-3
LOGIQ E9 XYZ
Motor Controller
with O-ring
Detection
5440179
Supports new LCD
Monitor introduced
with R4.x consoles
N/A
GA200952 GA200535
Backward
compatible
If replacing this part, it is recommended for
better performance to check the installed XYZ
Motor Controller and update it to 5429346 if
5429346 is not installed yet.
NOTE: 5429346 is ONLY compatible with
P/N GA200946 XY Mech.
5393698
XY Brake
Mechanism
Assembly
(USA Mfg.)
GA200952
Backward
compatible
If replacing this part, it is recommended for
better performance to check the installed XYZ
Motor Controller and update it to 5429346 if
5429346 is not installed yet.
NOTE: 5429346 is ONLY compatible with
P/N GA200946 and 5954000 XY Mech.
