GE LOGIQ E9 Service Manual

GE
D
IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL
9 - 100 Section 9-17 - Internal Cables
9-17-6 Peripherals Cables
Figure 9-15 Peripherals Cables (R4.x and later DVD shown in Figure 9-16)
Figure 9-16 DVD - R4.x and later
Table 9-45 Peripherals Cables
ITEM PART NAME PART NUMBER DESCRIPTION QTY FRU
1. Cable, DVD Power, FREY 5266407
Cable K
(J30 - DVD 1)
1Y
2. Cable, SATA Cable - External to DVD 5270048
Cable M
(J3 - DVD 1)
1Y
3. Cable-powered eSATA to 15-7 DVD 5431110
Cable M
(J3 - DVD 1)
1Y
4. Cable, USB Cable - BW Printer 5194492-2
Cable Q
(J26 - BW Printer)
1Y
BW
PRINTER
(OPTIONAL)
USB
PWR
TO MAIN PWR
SUPPLY
Q
Y
DVD 1
SATASATA PWR
DVD ADAPT PWA
BAYBIRD
(VGU OPTION)
USB
POWER
K
Z
M
R
M
DVD 1
SATASATA PWR
BEP J29-J32 DVD POWER
5266407 REV
BEP J3 / J2
5270048 REV
DVD UPPER / LOWER
SATA
SATA
BEP J3 / J2
DVD UPPER / LOWER
5431110 REV X #NAME# #ORIGIN# #DATE#
BEP J26
BW PRINTER
(610 mm)

GE LOGIQ E9 Specifications

General

Type	Ultrasound System
3D/4D Imaging	Yes
Transducer Ports	4 active ports
Connectivity	DICOM, USB, Ethernet
Applications	Abdominal, Vascular, Musculoskeletal, Small Parts, Urology, Pediatric, Cardiac, Obstetrics/Gynecology
Transducers	Linear, Convex, Phased Array, Volume
Doppler Modes	Color Doppler, Power Doppler, Pulsed Wave Doppler, Continuous Wave Doppler
Elastography	Yes
Advanced Features	B-Flow, Volume Navigation
Portability	Cart-based system
Display	19-inch high-resolution LCD monitor
