Inspection and Maintenance — GEK 107048Combustion Inspection — Disassembly Procedures
CI-D-6
Aft
Support
Bracket
Body
TOP VIEW
Aft
Floating Seal
Floating Seal
Forward
Support
SIDE VIEW
Figure CI–D.5. Transition Piece.
Frame
