GE MS-6001B - Transition Piece Support Clamp Assembly

Combustion Inspection — Reassembly ProceduresInspection and Maintenance — GEK 107048
CI-R-3
Figure CI-R.2. Transition Piece Support Clamp (Bullhorn) Assembly.
Combustion Liner
Transition Piece
Front Support Clamp
Forward
Mounting Block
“Shim”
Compressor Discharge
Casing
Flow
Sleeve
View “A”
Bend at Least
Two Tabs
Per Assembly
VIEW “A”
.01
.00
(Typ)
Bend at Least
Two Tabs
Per Assembly
(Bullhorn)
