Inspection and Maintenance — GEK 107048Major Inspection — Disassembly Procedures
MI-D-20
Figure MI-D.9. Inner Compressor Discharge Casing with Upper Half Removed.
Compressor
Rotor and Stator
Balance Weight
and Plane
Compressor Exit
Guide Vanes
Lower Half
Inner Compressor
Discharge Casing
