Hot Gas Path Inspection — Disassembly ProceduresInspection and Maintenance — GEK 107048
HGP-D-23
Figure HGP-D.13. Second and Third-Stage Nozzle Segments.
Nozzle
Partitions
Nozzle
Segment
Cooling Air
Exit Openings
Nozzle
Segment
Diaphragm
Segment
Seal
Teeth
Nozzle
Partitions
