GE MS-6001B - Crossfire Tube Assembly; Location of Crossfire Tube Spring Retainer

Inspection and Maintenance — GEK 107048Combustion Inspection — Disassembly Procedures
CI-D-16
Crossfire
Tube Spring
OuterPacking
Casing
Inner
Tubes
Outer
Tube
Flow
Sleeve
Cap &
Liner
Sealing
Ring
Split
Washer
Figure CI-D.13. Crossfire Tube Assembly.
Figure CI-D.14. Location of Crossfire Tube Spring Retainer.
Casing
Crossfire Tube
Spring Retainer
.614 Ref.
Retainer
