Hot Gas Path Inspection — Reassembly ProceduresInspection and Maintenance — GEK 107048
HGP-R-5
Figure HGP-R.2. First-Stage Nozzle Tangential Support Pin and Hardware Assembly.
First Stage Universal
Nozzle Segment
(Typical 18 Places)
Retainer
Bolt
Retainer and
Lockplate
Support
Pin
Compressor
Discharge Casing
Inner Barrel
Shim
Universal
Nozzle
Support Ring
Forward
Flange
Support Lug and Slot
Retainer Bolt
Lockplate
Support Pin
Bushing
Nozzle
A
A
View A–A
