GE MS-6001B - Tool, Transition Piece Side Clearance; Tool, Transition Piece, First Stage Nozzle

Standard PracticesInspection and Maintenance — GEK 107048
SP-23
Figure 2-11. Tool, Transition Piece Side Clearance.
Approx.
10
0.53 0.36
0.200
Typ
Approx. 5″
1/2″
1/2″
10″
.160″
.090″ 70°
.200 TYP.
3/16″ thru Hole
Figure 2-12. Tool, Transition Piece, First Stage Nozzle.
