GE MS-6001B - Major Inspection Recommended Spare Parts

Inspection and Maintenance — GEK 107048Standard Practices
SP-50
MS-6001B DLN-1 — Hot Gas Path Inspection Recommended Spare Parts (Cont’d)
Recommended
Quantity
BOLTING AND DOWELING ARRANGEMENT (ML1604) (Cont’d)
2. Nut, Twelve Point (Compressor Discharge Casing to Turbine Casing) Casing) *8
3. Bolt, Twelve Point Head (Turbine Casing to Exhaust Frame) *5
Note: The above quantities cover approximately 20% of the top half casings
bolting requirements only.
CASE MACHINING TURBINE (ML0705) (Turbine Casing Horizontal Flange Hardware)
1. Stud *1
2. Nut, Twelve Point *9
3. Bolt, Twelve Point *5
4. Bolt, Twelve Point *1
5. Stud, Body Bound *1
6. Stud *1
7. Stud *1
PLENUM ASSEMBLY, EXHAUST (ML1625)
1. Bolt, Hex Head (.500-13 x 1.250) 28
2. Expansion Joint, Segment (Forward Section) 14
3. Gasket, Exhaust Plenum (Forward Section) 1
DUCT, TRANSITION EXHAUST (MLA042)
**1. Gasket, Forward Exhaust Transition Piece Removable Panel 1
THERMOCOUPLES, EXHAUST AND TRIP (ML0623)
1. Exhaust and Trip Thermocouples 16
MS-6001B DLN-1
Major Inspection
Recommended Spare Parts
Note: Refer to your Parts Volume of this Service Manual to obtain the proper
drawing and/or part number for the material listed under each ar-
rangement or assembly drawing.
Recommended
Quantity
PRIMARY FUEL NOZZLE ASSEMBLY (ML0513)
1. Tip Assembly (Gas) 50
